The small mobile crushing station is a kind of mobile stone crushing equipment. The complete set of the mobile crushing station is a mechanical equipment that carries out multi-stage crushing of large materials and screens them according to certain discharge specifications. Check here the small stone crusher machine price in Russia.
YG Small stone crusher machine – Crushing and screening equipment
Machine output: 20t/h -450t/h
Maximum aggregate diameter: 900mm
Finished aggregate diameter: 1mm-50mm (Adjustable)
You can customize the processing according to the type and scale of raw materials processed. Various configurations are adopted depending on the material requirements of the finished product.
Applicable materials
Artificial sand made from river pebbles, mountain rocks (limestone, granite, basalt, diabase, andesite, etc.), ore tailings, and stone chips.
Read also: How to deal with construction waste? What equipment is used?
Technical Parameters
| Model | Max.feed size | Adjustment range | Capacity | Main shaft |
| YG-150X250 | 125mm | 10-40mm | 1-3m³/h | 285r/min |
| YG-200X300 | 165mm | 20-70mm | 2-8m³/h | 265r/min |
| YG-250X400 | 210mm | 20-80mm | 5-20m³/h | 310r/min |
| YG-400X600 | 340mm | 40-90mm | 10-40m³/h | 275r/min |
| YG-350X750 | 290mm | 30-55mm | 20-50m³/h | 255r/min |
| YG-500X750 | 425mm | 50-100mm | 34-68m³/h | 250r/min |
| YG-600X900 | 480mm | 75-200mm | 40-120m³/h | 250r/min |
| YG-750X1060 | 630mm | 80-200mmm | 80-160m³/h | 250r/min |
| YG-900X1200 | 750mm | 100-200mm | 110-200m³/h | 200r/min |
| YG-1000X1200 | 850mm | 195-265mm | 315-500m³/h | 180r/min |
| YG-1200X1500 | 1020mm | 150-300mm | 400-800m³/h | 300r/min |
Applications
Mobile crushing stations are mainly used for material processing that often require relocation operations in metallurgy, chemical industry, building materials, water and electricity, etc., especially for mobile stone operations such as highways, railways, and water and electricity projects.
What is the small stone crusher machine price? Please contact our expert.
24-hour hotline: +8613598866720
Types of mobile stone crusher machine
The classification of mobile crushing stations mainly includes:
- Jaw mobile crushing station
- Impact mobile crushing station
- Cone mobile crushing station
- Impact mobile crushing station
- Mobile screening station
- Crawler-type hydraulically driven mobile station
- Tire-type mobile crushing station.
Why you should choose a mobile small stone crusher machine?
- It can be driven directly to the site, with convenient transition operations.
- High screening efficiency and large output.
- The belt conveyor adopts full hydraulic control and is flexible and lightweight in multiple states of folding and shrinking.
- It is very suitable for operations in complex terrain areas such as narrow sites and urban demolition.
