In the fence mesh production industry, chain link machine for sale has become the first choice of equipment to improve production efficiency and reduce labor costs. chain link fence machine series products introduced by YG Machinery are suitable for diamond mesh weaving with various wires and holes, and support automatic weaving, cutting and winding. Automatic weaving, automatic cutting and winding, especially suitable for mass production and customized demand.
Chain Link Fence Machine Parameters
YG provides two main models, which can be flexibly selected according to different capacity requirements, and can be customized with parameters such as wire diameter, hole diameter, width, voltage, etc., to meet the needs of personalized production.
| Model | YG-20-100 | YG-25-80 |
| Wire diameter | 1.3-4mm | 2-4mm |
| Mesh size | 20-100mm | 25-100mm |
| Mesh width | 0.5-4m | 0.5-4m |
| Speed | 70-80m²/h | 120-180m²/h |
| Mesh length | 30m, adjustable freely as promised | |
| Mesh side | Knuckled and twisted, or knuckle, or twisted | |
| Raw material | Galvanized wire, PVC-coated wire, etc. | |
| Machine size | 4.2*2.2*1.7m | 6.7*1.43*1.8m |
| Weight | 2000kg | 4200kg |
| We can design the machine according to your wire diameter, mesh hole size, mesh width, and voltage. | ||
Customer FAQ & Q&A
Can finished fence mesh specifications be customized?
Of course you can, the following is the common range:
Aperture: 25mm-100mm adjustable
Mesh width: Maximum 4 meters (can be customized to 6 meters)
Wire diameter: 1.5mm – 4.5mm
📌 Customer question: “I need to produce 3 meters wide, 50×50mm fence mesh can I?”
✅ Answer: no problem at all, we can customize the equipment parameters according to your needs.
Equipment Requirements for Site and Power Supply?
Covering a compact area, 20~30 square meters can layout the complete production line.
The power supply is standardized as 380V three-phase electricity, with optional transformer adapted to 220V environment.
📌 Customer question: “My factory is 220V, can it run?”
✅ Answer: yes, we can provide you with transformer solutions adapted to the voltage.
What are the scenarios that the finished fence is suitable for?
Agriculture and animal husbandry: chicken, duck, rabbit and other breeding pen fences;
Infrastructure: road guardrail, construction site fence;
Public facilities: sports field fence, gardening protection;
Industrial use: storage area isolation, anti-theft fence.
📌 Customer question: “I mainly do fencing for agriculture, is this equipment suitable?”
✅ Answer: very suitable, you can adjust the mesh and wire diameter according to the use scene.
After-Sales Service and Tool Life?
The general tool life is 6-12 months, depending on the frequency of use.
We provide original wearing parts package, with operation manual and maintenance guide included in the shipment.
Lifetime technical support, after-sales engineers are available for remote or on-site service.
📌 Customer question, “What should I do if the tool is broken? Do you provide replacement parts?”
✅ ANSWER: we provide a full set of spare parts and can replenish or courier replacement parts at any time.
Frequently Asked Questions
Q1: Can the chain link fence machine adjust hole size?
Yes, the hole size from 25mm to 100mm can be set on the touchscreen panel.
Q2: Is it fully automatic?
Yes, it supports fully automatic weaving, cutting, and rolling with PLC control.
Q3: What’s the production capacity?
Around 70-180㎡ per hour depending on wire diameter and mesh size.
Q4: Can one operator handle the machine?
Yes, the system is designed for single-person operation.
Why Choose YG Chain Link Fence Mesh Machine?
- Multi-model optional, support personalized customization;
- High degree of automation, simple operation and convenient maintenance;
- Stable performance, suitable for global export;
- Professional after-sales team, support remote assistance and overseas guidance installation.
The chain link fencing machine price will fluctuate according to the configuration, voltage customization, transportation mode, welcome to contact us anytime for a detailed quotation and technical information. WhatsApp/WeChat/Phone】+86 13837115193.
We also produce the following products: barbed wire making machines, wire mesh welding machines, punch and shear, etc.
