Need a safe and efficient way to work at height in a warehouse, factory, commercial building, or maintenance facility? An electric scissor lift provides a vertically rising work platform for tasks that require workers, tools, and materials to be lifted to an elevated position.
YG Machinery offers electric scissor lift models with different platform heights, load capacities, platform sizes, and machine dimensions. Whether you need a lift for overhead maintenance, equipment installation, or building repairs, choosing the right configuration can help you work more efficiently while avoiding unnecessary equipment costs.
Looking for an electric scissor lift for sale? Tell us your required platform height, load capacity, access dimensions, and working environment. Our team can help you identify a suitable model and provide a quotation.
Electric Scissor Lift Models and Specifications
Choosing a scissor lift is not just about maximum height. You also need to consider how much weight the platform must carry, whether the machine can pass through site access points, and how much room workers need to complete the job.
Compare the following model specifications to narrow down your options.
| Model | Platform Height | Rated Load | Platform Size (L × W) | Overall Dimensions (L × W × H) | Lifting Motor | Machine Weight |
|---|---|---|---|---|---|---|
| YG0608SP* | 5.8 m | 230 kg | 1.67 × 0.74 m | 1.86 × 0.76 × 1.84 m | 24 V / 3.3 kW | 1,580 kg |
| YG0810NP* | 8 m | 230 kg | 2.27 × 0.81 m | 2.48 × 0.83 × 1.99 m | 24 V / 3.3 kW | 2,260 kg |
| YG1012 | 10 m | 320 kg | 2.27 × 1.12 m | 2.48 × 1.19 × 1.91 m | 24 V / 3.3 kW | 2,640 kg |
| YG1214 | 11.8 m | 320 kg | 2.27 × 1.12 m | 2.48 × 1.19 × 2.03 m | 24 V / 3.3 kW | 2,980 kg |
| YG1416 | 13.7 m | 230 kg | 2.64 × 1.12 m | 2.85 × 1.25 × 2.105 m | 24 V / 3.3 kW | 3,600 kg |
*Please confirm the model codes and configurations marked for review before publishing this table. All specifications should be checked against the manufacturer’s current technical documents.
Important: Platform height and working height are different measurements. Ask us to confirm the rated working height, operating limits, and configuration for your application.
Why Choose an Electric Scissor Lift?
1. Reach the Required Working Height
Choosing a lift that matches your working height helps you avoid paying for unnecessary lifting capacity or selecting equipment that cannot reach the job area.
Electric scissor lifts raise the platform vertically, making them suitable for overhead tasks such as lighting maintenance, installation work, and repairs in buildings with appropriate floor conditions.
Before ordering, confirm the required platform height and working height separately. Also consider the height of the ceiling, overhead structures, and the space needed to position the machine.
2. Carry Workers, Tools, and Materials
The platform’s rated load determines how much weight it can safely support. Depending on the model, this includes workers, tools, and materials carried onto the platform.
For example, the models listed above have rated loads ranging from 230 kg to 450 kg, subject to confirmation of the relevant configurations.
When choosing a lift, calculate the total load required for the job rather than considering the worker’s weight alone. Never exceed the manufacturer’s rated capacity or permitted occupant limit.
3. Fit Through Doors and Narrow Access Routes
A lift that reaches the required height may still be unsuitable if it cannot pass through a doorway or move along the site’s access route.
Check the machine’s overall width, length, and stowed height before ordering. Compare these measurements with door openings, warehouse aisles, lifts, ramps, and storage areas.
If access is restricted, tell us the available doorway width and height. We can help you compare suitable machine dimensions. Do not assume a model is suitable for narrow access until its actual dimensions and turning requirements have been verified.
4. Support Indoor Maintenance and Installation
Electric scissor lifts can be a practical choice for indoor work where a stable, level floor and suitable operating conditions are available.
Typical applications include:
- Warehouse lighting and overhead maintenance
- Factory equipment installation and servicing
- Electrical and HVAC installation
- Interior painting and building repairs
- Maintenance in commercial facilities
Before use, confirm floor load capacity, surface condition, operating clearance, charging arrangements, and the manufacturer’s indoor-use requirements. Outdoor use should only be considered when the specific model is approved for the intended ground and weather conditions.
5. Select a Platform That Matches the Job
Platform size affects how much room workers have for tools and materials. A larger platform may improve working space, but it can also increase the machine’s overall dimensions.
Consider the work area, the number of workers permitted on the platform, the materials being carried, and the route to the job site. Choose a platform that meets the application requirements without creating unnecessary access problems.
How to Choose the Right Electric Scissor Lift?
Before requesting a quotation, prepare the following information:
- Required height: Specify the required platform height and working height. These are not interchangeable.
- Load capacity: Estimate the combined weight of workers, tools, and materials.
- Access dimensions: Measure the narrowest doorway or aisle and the available height for moving the lift in its stowed position.
- Working environment: Tell us whether the lift will be used indoors or outdoors, and describe the floor surface and site conditions.
- Platform size: Explain how much room is needed for workers, tools, and materials.
- Order and delivery requirements: Confirm the destination country, quantity, delivery expectations, and any local compliance requirements.
Providing these details helps reduce the risk of choosing a lift that is too large, too small, or unsuitable for the work site.
Electric Scissor Lift Price and Quotation
The price of an electric scissor lift depends on its platform height, rated load, platform dimensions, configuration, order quantity, and delivery destination.
A higher platform or greater load capacity does not automatically make a model the best choice for every project. Selecting equipment based on actual site requirements can help you avoid paying for specifications you do not need.
For an accurate quotation, send us:
- Required platform height and working height
- Rated load capacity
- Available access width and height
- Indoor or outdoor application
- Order quantity and destination country
Our team can review your requirements and provide available model options, verified specifications, and a quotation.
Electric Scissor Lift vs. Boom Lift
An electric scissor lift and a boom lift serve different access requirements.
| Comparison | Electric Scissor Lift | Boom Lift |
|---|---|---|
| Main movement | Vertical lifting | Vertical lifting with horizontal outreach, depending on type |
| Typical use | Overhead work directly above the machine | Work that requires reaching over or around obstacles |
| Platform | Usually a larger rectangular work platform | Usually a smaller work basket |
| Key selection factor | Platform height, rated load, and machine dimensions | Working height, horizontal outreach, and obstacle clearance |
If your work requires reaching around obstacles or accessing a position away from the machine, an articulating or telescopic boom lift may be more suitable. If you need a platform for vertical access, a scissor lift may be the better fit.
FAQ about Scissor Lift
1.What is an electric scissor lift used for?
An electric scissor lift is used to raise workers, tools, and materials for elevated tasks such as maintenance, installation, repairs, and warehouse work, provided the site conditions meet the manufacturer’s requirements.
2.What is the difference between platform height and working height?
Platform height measures the height of the platform above the ground. Working height is a separate rating commonly used to describe the approximate height a person can reach while standing on the platform. Always compare machines using the manufacturer’s stated measurements.
3.How much weight can an electric scissor lift carry?
Load capacity varies by model and configuration. The specifications listed on this page range from 230 kg to 450 kg, pending verification of the relevant model codes. The total load must remain within the manufacturer’s rated capacity.
4.Can an electric scissor lift be used outdoors?
Outdoor use depends on the specific model, ground conditions, wind limits, and manufacturer instructions. Confirm that the machine is approved for the intended environment before operating it outdoors.
5.How do I choose a scissor lift for a narrow doorway?
Measure the narrowest doorway and the available clearance, then compare these measurements with the machine’s stowed dimensions. Also check turning space, floor conditions, and any ramps along the route.
6.How can I get a quotation for an electric scissor lift?
Send us your required platform height, load capacity, access dimensions, working environment, order quantity, and destination country. We can then review the requirements and recommend suitable available models.
Request a Quote for an Electric Scissor Lift
Looking for an electric scissor lift for your warehouse, factory, or maintenance project?
Contact YG Machinery with your working height, load requirements, site dimensions, and delivery destination. We will help you compare suitable models and request a quotation based on your application.
