Removing accumulated sludge from industrial tanks and wastewater treatment facilities can be difficult when the sediment is thick, access is restricted, or manual cleaning requires workers to enter the tank.
For an industrial customer in Australia, YG Machinery was approached to discuss a remote-controlled sludge removal solution for demanding cleaning conditions. The project highlights the role of sludge removal robots in reducing manual handling and supporting more efficient industrial tank maintenance.
The appropriate equipment configuration depends on the tank dimensions, sludge characteristics, access conditions, and required pumping performance.
Looking for a solution for your industrial sludge removal project? Contact our team to discuss your application and request a quotation.
Automatic Sludge Removal Robot Parameters
| Parameter | YG500 | YG600 | YG700 | YG800 | YG900 | YG1200 |
| Robot Dimensions (mm) | 1500*500*650 | 1500*600*650 | 1600*700*650 | 1600*850*700 | 1650*960*750 | 1900*1200*750 |
| Dredging Width (mm) | 500 | 600 | 700 | 800 | 900 | Suitable for large culverts |
| Travel Speed (m/s) | 3–15 | 3–15 | 3–15 | 3–15 | 3–15 | 0–17 m/min |
| Pump Diameter (inch) | 3 | 3 | 4 | 4 | 4 | 4or6 |
| Pump Flow (m³/h) | 100 | 100 | 160 | 160 | 200 | 250 |
| Pump Head (m) | 0–30 | 0–30 | 0–25 | 0–25 | 0–25 | 0–30 (Horizontal: 100–150m) |
| Hydraulic Station Dimensions (mm) | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2120*1240*1200 |
| Main Motor Power (kW) | 18 | 18 | 22 | 22 | 22 | 45KW (50KW) or Diesel 76KW (123KW) |
| Hydraulic System Pressure (Mpa) | 0–16 | 0–16 | 0–16 | 0–16 | 0–16 | Not specified |
| Particle Size (mm) | 15 | 15 | 40 | 40 | 50 | 0–40 (customizable) |
| Winch Speed (r/min) | 0–10 | 0–10 | 0–10 | 0–10 | 0–10 | 0–10 |
| Pipe Length (m) | 30–50 Optional | 30–50 Optional | 30–50 Optional | 30–50 Optional | 30–50 Optional | 30m/pack, 20kg pressure resistant, optional |
| Control System | Wireless Remote | Wireless Remote | Wireless Remote | Wireless Remote | Wireless Remote | Wireless Remote |
| Lighting System | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 |
Industrial Sludge Removal Challenges
Industrial facilities can accumulate sludge and sediment in wastewater treatment tanks, sedimentation basins, and circulating water collection pools. When deposits build up over time, conventional cleaning methods may require substantial manual work and equipment preparation.
The main challenges include:
- Difficult Access to Tanks and Basins: Some industrial tanks have limited access openings or confined working areas. Bringing conventional excavation or cleaning equipment into these spaces may be impractical. A compact, remote-controlled dredging robot can help address suitable applications where equipment access and working clearance are limited.
- Thick Sludge and Accumulated Sediment: Industrial sludge can contain fine solids, sand, mineral deposits, organic matter, or other process residues. Its consistency and solids content affect how easily the material can be loosened, collected, and pumped. Equipment selection should therefore consider the sludge composition, particle size, viscosity, and required discharge distance.
- Manual Cleaning Requirements: Manual tank cleaning may involve demanding working conditions, additional labor, and careful safety planning. Remote operation can reduce the need for personnel to enter the immediate cleaning area, provided the equipment and operating method are suitable for the site.
- Maintenance Downtime: Accumulated sludge can interfere with routine tank maintenance and reduce usable tank capacity. An appropriate sludge removal system can help streamline cleaning operations and support planned maintenance schedules.
YG’s Remote-Controlled Sludge Removal Solution
For suitable industrial cleaning applications, YG’s sludge removal robot combines remote-controlled movement with a sludge collection and pumping system.
The final configuration should be selected according to the customer’s tank layout, sludge properties, and site requirements.
- Remote-Controlled Operation: Remote control allows the operator to guide the robot from a suitable operating position rather than manually directing equipment inside the cleaning area. Actual operating range and supported functions depend on the selected configuration.
- Sludge Collection and Pumping: The robot’s collection mechanism and pump work together to remove suitable accumulated sludge and transfer it through a discharge pipeline. Pump selection must account for the material’s solids content, particle size, viscosity, and required delivery conditions. For hardened or heavily compacted deposits, additional sludge-breaking or loosening measures may be necessary.
- Compact Tracked Movement: A tracked configuration can help the robot move across suitable tank floors and sediment-covered surfaces. Access opening dimensions, floor conditions, tank geometry, and the robot’s overall dimensions must be checked before deployment.
- Configuration Based on Site Conditions: The robot can be evaluated for suitable wastewater treatment tanks, sedimentation basins, industrial sludge collection areas, and other confined-access cleaning applications. Applications involving corrosive chemicals, combustible atmospheres, or other hazardous conditions require a separate technical and safety assessment before equipment selection.
FAQ about Sludge Removal Robot
1. What types of sludge can the robot remove?
Suitability depends on the sludge’s composition, viscosity, solids content, and particle size. Provide a sample description or photographs of the material so the equipment configuration can be assessed.
2. Can the robot operate in confined tanks?
It can be considered for suitable confined-access applications. The tank entrance, internal dimensions, floor conditions, and required operating clearance must be checked before deployment.
3. Does remote operation eliminate the need for confined-space safety procedures?
No. Remote operation can reduce the need for personnel to enter the cleaning area, but it does not eliminate site hazards or replace the required confined-space risk assessment and safety procedures.
4. How do I choose the correct pump capacity?
Pump selection depends on the sludge characteristics, required flow rate, discharge distance, pipeline dimensions, and elevation changes. The rated water flow alone may not represent the actual sludge-handling capacity.
5. Can the robot be customized for industrial applications?
Configuration options should be confirmed against the selected model and project requirements. Applications involving corrosive substances or potentially explosive atmospheres require specific compatibility and safety verification.
6. How can I obtain a quotation?
Please provide the tank dimensions, access opening size, sludge type, estimated sediment depth, required discharge distance, and project location. Photographs or videos of the site can also help our team assess a suitable configuration. crates, end-to-end logistics services in Australia, and online video support for installation and commissioning.
Why are Australian customers increasingly choosing YG Machinery?
- 20+ countries of experience in dredging projects, mature solutions;
- Customizable to meet special needs such as explosion-proof, extended hoses, and increased pump flow rates;
- Mature unmanned dredging technology, suitable for high-risk chemical environments;
- Prices significantly lower than European and American brands, while offering comprehensive functionality;
- 24/7 after-sales support, with an English-speaking technical team.
Remote Controlled Dredging Robot in YG Machinery
This Australian client’s success story demonstrates that whether it’s chemical plant sedimentation tanks, oil tank bottoms, or municipal lake remediation, YG’s automatic sludge removal robot, remote-controlled dredging robot can provide reliable, safe, and efficient solutions.
If you also need an environmental sludge cleaning robot suitable for hazardous areas, with high environmental requirements, and challenging cleaning conditions, please feel free to contact YG Machinery for solutions and quotes. 【WhatsApp/WeChat/Phone】+86 13837115193.
